Heavy-duty electric winch (1.8 hp), manual rotation, manual extension, and a folding boom.
Third Place Winner in Lift Applications & Equipment's 2003 Pinnacle Award Competition for cranes (100 tons or less capacity).
- Meets ANSI B30.5 safety standards
- Mounting sockets allow easy crane removal for multiple operation locations and varied uses of vehicle
- 360-degree Manual Rotation with 8-position base lock to hold mast firmly in position while in use and while traveling
- Composite polymer and bronze self-lubricating rotation bearings are not sensitive to water, dirt, or chemical contamination
- Standard Equipment: Remote Control Pendant: 15 FT. Cord with Quick Disconnect
- Standard Equipment: Master Disconnect Switch Kit
- Standard Equipment: 35 FT. of 3/16" Wire Rope (optional cable lengths up to 75 FT.)
- Standard Equipment: Load Block with Swivel Hook and Safety Latch
- Standard Equipment: Battery Cable: 25 FT., 4-Gauge
- Standard Equipment: Weight: 195 – 205 LBS.
- Optional Equipment:Recessed or surface mounting sockets for multiple operating locations
- Optional Equipment:Short mast for mounting on top of utility body
- Optional Equipment:AC winch for in-plant use
- Optional Equipment:Wire ropes up to 75 FT. in length
- Optional Equipment:Outrigger packages for all styles of bodies
- Optional Equipment:250 AMP Circuit Breaker Kit
