Knapheide PGND Gooseneck Body
KNP:PGND-EQP
Most Flatbeds and Service Bodies Require Your Truck be ¾ Ton or Higher Capacity.
Please Call for Availability
800-346-1704
Description
PGND Gooseneck Bodies. Versatility with storage solutions to meet every need,
Knapheide Gooseneck Bodies are an easy choice. Rugged construction, enhanced styling and secure storage give you a body that can haul it all.
- Under-the-floor gooseneck hitch system with 2-5/16" ball installed (hitch is rated at 30,000 lb. gross trailer weight with 5,000 lb. tongue weight)
- Features double-shell, 20-gauge, two-sided A-40 galvanneal steel compartment doors
- Rugged 1/8" thick tread plate floor with 5" structural channel long sills
- Three-quarter length flip top compartments employ nitrogen gas struts for smooth opening and closing.
- Flip top compartments stretch from aft of the front compartment, all the way to the rear of the body.
- Flip top operating handle is placed inside the front compartment for maximum security.
- Aluminum tread plate trim piece on rear hitch plate provides a "no worry" step location
- 36" high front side packs allow for maximum trailer swing radius
- Durable oven-cured coat, finish painted black
- Rugged 14-gauge two-sided A-40 galvanneal steel body shell
- Neoprene door seals protect compartments from the weather
- Continuous stainless steel hinges are pry-proof and corrosion-resistant
- 250-lb. capacity shelves made of spangled steel (2 in each front vertical compartment, 1 in each rear compartment)
- 3" formed 12-gauge cross sills
- 8" tall slam tailgate with center-mounted single hand operation release handle (standard)
- Bulkhead and rear skirt include integrated oval B/U and S/T/T LED lights
- Updated bulkhead punch pattern provides greater visibility and stylized screen window design
- Hinged access door to cover gooseneck hitch when not in use
- Automotive quality, rotary-style latches make opening and closing easy. Interior cover protects internal latch from damage.
- Integrated Class V receiver hitch rated at 12,000 lb. (optional on 8' bodies as most 56" CA chassis include a factory hitch)
- Safety chain attachment points and 7-way trailer plug included in gooseneck box and at receiver hitch
- Adjustable security ring strikers provide a weather-tight seal
- Double-spring over-center door retainer eliminates involuntary door swing
- All marker, clearance and I.D. lights are LED
- Integrated driver side fuel fill cup
- Electrodeposition prime-paint system provides superior corrosion resistance
- POPULAR OPTIONS:
- Additional Aluminum Tread Plate Overlay
- Cargo D-Rings
- C-Tech Drawer Sets
- Power Locks
- LED Compartment Lights
- 3/16" Tread Plate Floor
