Knapheide PGNC Gooseneck Body

Click on image to zoom

California Residents: Prop 65 Warning

WARNING: Cancer and Reproductive Harm

www.p65warnings.ca.gov

KNP:PGNC-EQP
  • Low Prices
  • Easy Returns
  • Expert Staff
Most Flatbeds and Service Bodies Require Your Truck be ¾ Ton or Higher Capacity.
Call For Best PriceCall For Best Price

Need an Installation Quote?

Description

PGNC Gooseneck Bodies. Versatility with storage solutions to meet every need, Knapheide Gooseneck Bodies are an easy choice. Rugged construction, enhanced styling and secure storage give you a body that can haul it all.
  • Under-the-floor gooseneck hitch system with 2-5/16" ball installed (hitch is rated at 30,000 lb. gross trailer weight with 5,000 lb. tongue weight)
  • Features double-shell, 20-gauge, two-sided A-40 galvanneal steel compartment doors
  • Rugged 12-gauge tread plate floor with 6" structural channel long sills (4" on 8' models)
  • Rub rails installed on both sides of platform for convenient cargo tie downs
  • Aluminum tread plate trim piece on rear hitch plate provides a "no worry" step location
  • Internal stake pockets lining both sides and rear of the platform
  • Durable oven-cured coat, finish painted black
  • Simplified rear skirt styling. Skirted gooseneck styling with integrated front and rear toolboxes. Toolboxes optimized to provide 20% additional storage capacity.
  • Neoprene door seals protect compartments from the weather
  • Continuous stainless steel hinges are pry-proof and corrosion-resistant
  • 12-gauge formed cross sills, spaced on 16" centers
  • Bulkhead and rear skirt include integrated oval LED B/U and S/T/T lights
  • Updated bulkhead punch pattern provides greater visibility and stylized screen window design
  • Hinged access door to cover gooseneck hitch when not in use
  • Automotive quality, rotary-style latches make opening and closing easy. Interior cover protects internal latch from damage.
  • Integrated Class V receiver hitch rated at 12,000 lb. (optional on 8' bodies as most 56" CA chassis include a factory hitch)
  • Safety chain attachment points and 7-way trailer plug included in gooseneck box and at receiver hitch
  • Adjustable security ring strikers provide a weather-tight seal
  • Double-spring over-center door retainer eliminates involuntary door swing
  • All marker, clearance and I.D. lights are LED
  • Integrated driver side fuel fill cup
  • Electrodeposition prime-paint system provides superior corrosion resistance
    • POPULAR OPTIONS:
    • Additional Aluminum Tread Plate Overlay
    • Roughneck Contractor Package
    • 4" Removable Side Boards
    • Above Body & Underbody Toolboxes
    • LED S/T/T Lights
    • 3/16" Tread Plate Floor
