Knapheide PGNB Gooseneck Body
KNP:PGNB-EQP
- Call for Availability
- Local: 509-755-5037
- Toll Free: 855-607-6390
- Low Prices
- Easy Returns
- Expert Staff
Most Flatbeds and Service Bodies Require Your Truck be ¾ Ton or Higher Capacity.
Need an Installation Quote?
Description
PGNB Gooseneck Bodies. Versatility with storage solutions to meet every need,
Knapheide Gooseneck Bodies are an easy choice. Rugged construction, enhanced styling and secure storage give you a body that can haul it all.
- Under-the-floor gooseneck hitch system with 2-5/16" ball installed (hitch is rated at 30,000 lb. gross trailer weight with 5,000 lb. tongue weight)
- Rugged 12-gauge tread plate floor with 6" structural channel long sills (4" on 8' models)
- Rub rails installed on both sides of platform for convenient cargo tie downs
- Aluminum tread plate trim piece on rear hitch plate provides a "no worry" step location
- Internal stake pockets lining both sides and rear of the platform
- Durable oven-cured coat, finish painted black
- 12-gauge formed cross sills, spaced on 16" centers
- Bulkhead and rear skirt include integrated oval LED B/U and S/T/T lights
- Updated bulkhead punch pattern provides greater visibility and stylized screen window design
- Hinged access door to cover gooseneck hitch when not in use
- Integrated Class V receiver hitch rated at 12,000 lb. (optional on 8' bodies as most 56" CA chassis include a factory hitch)
- Safety chain attachment points and 7-way trailer plug included in gooseneck box and at receiver hitch
- All marker, clearance and I.D. lights are LED
- Integrated driver side fuel fill cup
- Electrodeposition prime-paint system provides superior corrosion resistance
- POPULAR OPTIONS:
- Additional Aluminum Tread Plate Overlay
- Roughneck Contractor Package
- 4" Removable Side Boards
- Above Body & Underbody Toolboxes
- LED S/T/T Lights
- 3/16" Tread Plate Floor
- Gooseneck Hitch and Trap Door Removal
