Knapheide PGNB Gooseneck Body

KNP:PGNB-EQP
Most Flatbeds and Service Bodies Require Your Truck be ¾ Ton or Higher Capacity.
Please Call for Availability
800-346-1704

Description

PGNB Gooseneck Bodies. Versatility with storage solutions to meet every need, Knapheide Gooseneck Bodies are an easy choice. Rugged construction, enhanced styling and secure storage give you a body that can haul it all.
  • Under-the-floor gooseneck hitch system with 2-5/16" ball installed (hitch is rated at 30,000 lb. gross trailer weight with 5,000 lb. tongue weight)
  • Rugged 12-gauge tread plate floor with 6" structural channel long sills (4" on 8' models)
  • Rub rails installed on both sides of platform for convenient cargo tie downs
  • Aluminum tread plate trim piece on rear hitch plate provides a "no worry" step location
  • Internal stake pockets lining both sides and rear of the platform
  • Durable oven-cured coat, finish painted black
  • 12-gauge formed cross sills, spaced on 16" centers
  • Bulkhead and rear skirt include integrated oval LED B/U and S/T/T lights
  • Updated bulkhead punch pattern provides greater visibility and stylized screen window design
  • Hinged access door to cover gooseneck hitch when not in use
  • Integrated Class V receiver hitch rated at 12,000 lb. (optional on 8' bodies as most 56" CA chassis include a factory hitch)
  • Safety chain attachment points and 7-way trailer plug included in gooseneck box and at receiver hitch
  • All marker, clearance and I.D. lights are LED
  • Integrated driver side fuel fill cup
  • Electrodeposition prime-paint system provides superior corrosion resistance
    • POPULAR OPTIONS:
    • Additional Aluminum Tread Plate Overlay
    • Roughneck Contractor Package
    • 4" Removable Side Boards
    • Above Body & Underbody Toolboxes
    • LED S/T/T Lights
    • 3/16" Tread Plate Floor
    • Gooseneck Hitch and Trap Door Removal

Application List

Universal

Details

  • KNP:PGNB-EQP
  • KNP:PGNB-EQP
  • Knapheide
  • New
